عرض 1–12 من أصل 81 نتيجة

Manifolds unit with memory flowmeters and valves – With straight ball valve

Codes and dimensions
Head connection Outlets Fitting thread Length total collector
1″ 2 3/4” EK. 1 295 mm
1″ 3 3/4” EK. 1 345 mm
1″ 4 3/4” EK. 1 395 mm
1″ 5 3/4” EK. 1 445 mm
1″ 6 3/4” EK. 1 495 mm
1″ 7 3/4” EK. 1 545 mm
1″ 8 3/4” EK. 1 595 mm
1″ 9 3/4” EK. 1 645 mm
1″ 10 3/4” EK. 1 695 mm
1″ 11 3/4” EK. 1 745 mm
1″ 12 3/4” EK. 1 795 mm
1″ 13 3/4” EK. 1 845 mm
1″ 14 3/4” EK. 1 895 mm
1″1/4 2 3/4” EK. 1 304 mm
1″1/4 3 3/4” EK. 1 354 mm
1″1/4 4 3/4” EK. 1 404 mm
1″1/4 5 3/4” EK. 1 454 mm
1″1/4 6 3/4” EK. 1 504 mm
1″1/4 7 3/4” EK. 1 554 mm
1″1/4 8 3/4” EK. 1 604 mm
1″1/4 9 3/4” EK. 1 654 mm
1″1/4 10 3/4” EK. 1 704 mm
1″1/4 11 3/4” EK. 1 754 mm
1″1/4 12 3/4” EK. 1 804 mm
1″1/4 13 3/4” EK. 1 854 mm
1″1/4 14 3/4” EK. 1 904 mm
Data Sheet TECHNICAL DATA SHEET

Manifolds unit with adjustment lockshields – With straight balla valve

Codes and dimensions
Art. Head connection Outlets Code Fitting thread Length total collector Box recommended Art. 196
K021 1″ 2 87K021PG06 3/4” EK. 1 295 mm 500 mm
K021 1″ 3 87K021PH06 3/4” EK. 1 345 mm 500 mm
K021 1″ 4 87K021PJ06 3/4” EK. 1 395 mm 500 mm
K021 1″ 5 87K021PQ06 3/4” EK. 1 445 mm 700 mm
K021 1″ 6 87K021PK06 3/4” EK. 1 495 mm 700 mm
K021 1″ 7 87K021PR06 3/4” EK. 1 545 mm 700 mm
K021 1″ 8 87K021PL06 3/4” EK. 1 595 mm 700 mm
K021 1″ 9 87K021PS06 3/4” EK. 1 645 mm 850 mm
K021 1″ 10 87K021PM06 3/4” EK. 1 695 mm 850 mm
K021 1″ 11 87K021PT06 3/4” EK. 1 745 mm 850 mm
K021 1″ 12 87K021PU06 3/4” EK. 1 795 mm 1000 mm
K021 1″ 13 87K021PV06 3/4” EK. 1 845 mm 1000 mm
K021 1″ 14 87K021PW06 3/4” EK. 1 895 mm 1200 mm
K021 1″1/4 2 87K021DG06 3/4” EK. 1 304 mm 500 mm
K021 1″1/4 3 87K021DH06 3/4” EK. 1 354 mm 500 mm
K021 1″1/4 4 87K021DJ06 3/4” EK. 1 404 mm 500 mm
K021 1″1/4 5 87K021DQ06 3/4” EK. 1 454 mm 700 mm
K021 1″1/4 6 87K021DK06 3/4” EK. 1 504 mm 700 mm
K021 1″1/4 7 87K021DR06 3/4” EK. 1 554 mm 700 mm
K021 1″1/4 8 87K021DL06 3/4” EK. 1 604 mm 700 mm
K021 1″1/4 9 87K021DS06 3/4” EK. 1 654 mm 850 mm
K021 1″1/4 10 87K021DM06 3/4” EK. 1 704 mm 850 mm
K021 1″1/4 11 87K021DT06 3/4” EK. 1 754 mm 850 mm
K021 1″1/4 12 87K021DU06 3/4” EK. 1 804 mm 1000 mm
K021 1″1/4 13 87K021DV06 3/4” EK. 1 854 mm 1000 mm
K021 1″1/4 14 87K021DW06 3/4” EK. 1 904 mm 1200 mm
K022 1″ 2 87K022PG06 M24x1,5 1 295 mm 500 mm
K022 1″ 3 87K022PH06 M24x1,5 1 345 mm 500 mm
K022 1″ 4 87K022PJ06 M24x1,5 1 395 mm 500 mm
K022 1″ 5 87K022PQ06 M24x1,5 1 445 mm 700 mm
K022 1″ 6 87K022PK06 M24x1,5 1 495 mm 700 mm
K022 1″ 7 87K022PR06 M24x1,5 1 545 mm 700 mm
K022 1″ 8 87K022PL06 M24x1,5 1 595 mm 700 mm
K022 1″ 9 87K022PS06 M24x1,5 1 645 mm 850 mm
K022 1″ 10 87K022PM06 M24x1,5 1 695 mm 850 mm
K022 1″ 11 87K022PT06 M24x1,5 1 745 mm 850 mm
K022 1″ 12 87K022PU06 M24x1,5 1 795 mm 1000 mm
K022 1″ 13 87K022PV06 M24x1,5 1 845 mm 1000 mm
K022 1″ 14 87K022PW06 M24x1,5 1 895 mm 1200 mm
Data Sheet TECHNICAL DATA SHEET

Manifolds unit with adjustment lockshields and valves

Manifolds unit with adjustment lockshields and valves with thermostatic option. Outlets for 1/2” air vent (art.700) and 1/2” drain cock (art.172). Brackets with anti-vibration supports (art.208). Suitable for 3/4” Euroconus or M24x1,5 fittings. Choose electrothermic actuators with 28×1,5 connection thread. Codes and dimensions
Art. Head connection Outlets Code Fitting thread Length total collector
K009 1″ 2 87K009PG06 3/4” EK. 1 104 mm
K009 1″ 3 87K009PH06 3/4” EK. 1 154 mm
K009 1″ 4 87K009PJ06 3/4” EK. 1 204 mm
K009 1″ 5 87K009PQ06 3/4” EK. 1 254 mm
K009 1″ 6 87K009PK06 3/4” EK. 1 304 mm
K009 1″ 7 87K009PR06 3/4” EK. 1 354 mm
K009 1″ 8 87K009PL06 3/4” EK. 1 404 mm
K009 1″ 9 87K009PS06 3/4” EK. 1 454 mm
K009 1″ 10 87K009PM06 3/4” EK. 1 504 mm
K009 1″ 11 87K009PT06 3/4” EK. 1 554 mm
K009 1″ 12 87K009PU06 3/4” EK. 1 604 mm
K009 1″ 13 87K009PV06 3/4” EK. 1 654 mm
K009 1″ 14 87K009PW06 3/4” EK. 1 704 mm
K010 1″ 2 87K010PG06 M24x1,5 1 104 mm
K010 1″ 3 87K010PH06 M24x1,5 1 154 mm
K010 1″ 4 87K010PJ06 M24x1,5 1 204 mm
K010 1″ 5 87K010PQ06 M24x1,5 1 254 mm
K010 1″ 6 87K010PK06 M24x1,5 1 304 mm
K010 1″ 7 87K010PR06 M24x1,5 1 354 mm
K010 1″ 8 87K010PL06 M24x1,5 1 404 mm
K010 1″ 9 87K010PS06 M24x1,5 1 454 mm
K010 1″ 10 87K010PM06 M24x1,5 1 504 mm
K010 1″ 11 87K010PT06 M24x1,5 1 554 mm
K010 1″ 12 87K010PU06 M24x1,5 1 604 mm
K010 1″ 13 87K010PV06 M24x1,5 1 654 mm
K010 1″ 14 87K010PW06 M24x1,5 1 704 mm
Data Sheet TECHNICAL DATA SHEET

Single distribution manifold

Single distribution manifold. 1/2” female side connections. Interaxe: 50 mm Codes and dimensions
Art. Head connection Outlets Side connection thread Code
1102 3/4 2 1/2 871102PA05 40
1102 3/4 3 1/2 871102PB05 30
1102 3/4 4 1/2 871102PC05 30
1102 3/4 5 1/2 871102PN05 20
1102 3/4 6 1/2 871102PD05 20
1102 3/4 7 1/2 871102PO05 20
1102 3/4 8 1/2 871102PE05 20
1102 3/4 9 1/2 871102PP05 10
1102 3/4 10 1/2 871102PF05 10
1102 1″ 2 1/2 871102PG05 30
1102 1″ 3 1/2 871102PH05 20
1102 1″ 4 1/2 871102PJ05 20
1102 1″ 5 1/2 871102PQ05 20
1102 1″ 6 1/2 871102PK05 20
1102 1″ 7 1/2 871102PR05 20
1102 1″ 8 1/2 871102PL05 20
1102 1″ 9 1/2 871102PS05 10
1102 1″ 10 1/2 871102PM05 10
1102 1″ 11 1/2 871102PT05 10
1102 1″ 12 1/2 871102PU05 10
1102 1″ 13 1/2 871102PV05 10
1102 1″ 14 1/2 871102PW05 10
1102 1″ 15 1/2 871102PY05 10
1102 1”1/4 2 1/2 871102DG05 30
1102 1”1/4 3 1/2 871102DH05 20
1102 1”1/4 4 1/2 871102DJ05 20
1102 1”1/4 5 1/2 871102DQ05 20
1102 1”1/4 6 1/2 871102DK05 20
1102 1”1/4 7 1/2 871102DR05 20
1102 1”1/4 8 1/2 871102DL05 20
1102 1”1/4 9 1/2 871102DS05 10
1102 1”1/4 10 1/2 871102DM05 10
1102 1”1/4 11 1/2 871102DT05 10
1102 1”1/4 12 1/2 871102DU05 10
1102 1”1/4 13 1/2 871102DV05 10
1102 1”1/4 14 1/2 871102DW05 10
1102 1”1/4 15 1/2 871102DY05 10

NADKED PE-Xb/Al/PE-Xb IN ROLLS

Codes and dimensions
Dimensions Aluminum Rolls Pallet
14X2 0.20 100 m 1800 m
16X2 0.20 100 m 2500 m
16X2 0.20 200 m 3000 m
16X2 0.20 250 m 3750 m
16X2 0.20 500 m 3000 m
18X2 0.20 100 m 1700 m
20X2 0.35 100 m 2100 m
20X2 0.25 100 m 2100 m
26X3 0.40 100 m 600 m
32X3 0.45 50 m 600 m

Towel warmers

We are delighted to present you our new range of Decorative Steel Towel Radiators: The Heating Constellation Decorative Steel Towel Radiators are available in seven different models: Pegasus 41, Pegasus 50, ANTARES, SIRIO CENTRAL, ELIPSE, TAURUS and VELA, they are manufactured with the following version: STRAIGHT – CURVED – WHITE – CHROME.
